Golden Bridge ER308L Stainless Steel TIG Filler Rod 1/16" 3/32" 1/8" x 39"
Golden Bridge ER308L Stainless Steel TIG Filler Rod 1/16" 3/32" 1/8" x 39"
SKU:JQ-TG308L-1/16-0020
Regular price
$33.99 USD
Regular price
Sale price
$33.99 USD
Unit price
per
In stock
Shipping calculated at checkout.
Couldn't load pickup availability
JQ-TG308L
JQ-TG308L is a gas shielded TIG welding wire of ultra-low carbon C-21Cr-10Ni austenitic stainless steel, which has excellent performance with smooth arc, low spatter level, good wire feeding behavior and optimal bead appearance. It is permitted for all-position welding. It has good crack resistance, and is suitable for welding of nonmagnetic, high manganese steel and hardened corrosion resistant steel.
The product is applicable for welding 022Cr19Ni10, and it is commonly used in the fields such as petrochemical industry, pressure vessel, food and medical treatment, construction machinery, nuclear power and so on.
Chemical components of welding wire (%)
Chemical components of welding wire (%)
Chemical components of welding wire (%)
|
Item
|
C
|
Mn
|
Si
|
Cr
|
Ni
|
Mo
|
P
|
S
|
Cu
|
| Example value | 0.024 | 1.72 | 0.48 | 19.76 | 9.83 | 0.006 | 0.018 | 0.010 | 0.06 |
Mechanical properties of deposited metal
|
Item
|
Rm
(MPa) |
A
(%) |
| Example value | 586 | 39 |
Reference current (AC, DC-)
|
Diameter (mm)
|
Φ1.6
|
Φ2.0
|
Φ2.5
|
Φ3.2
|
| Welding current(A) | 50-100 | 100-200 | 200-300 | 300-400 |
1. Shielding gas: Adopt pure Ar; Flow: 9-14L/min when the current is 100-200A, and 14-18L/min when the current is 200-300A.
2. Extension length of tungsten wire: 3-5mm; Arc length: 1-3mm.
3. Keep the wind speed ≤ 1.0m/s; It is suggested that argon should be introduced to the back of the welding zone for protection.
4. Pay more attention on the heat input during welding process as it will directly affect the mechanical properties and crack resistance of the weld metal.
5. The rust layer, moisture, oil stain, dust, etc. on the welding part shall be clearly removed.
The above suggestions are for reference only, and specific operation should be made according to the onsite conditions. When necessary, conduct process evaluation before determining the welding scheme.
2. Extension length of tungsten wire: 3-5mm; Arc length: 1-3mm.
3. Keep the wind speed ≤ 1.0m/s; It is suggested that argon should be introduced to the back of the welding zone for protection.
4. Pay more attention on the heat input during welding process as it will directly affect the mechanical properties and crack resistance of the weld metal.
5. The rust layer, moisture, oil stain, dust, etc. on the welding part shall be clearly removed.
The above suggestions are for reference only, and specific operation should be made according to the onsite conditions. When necessary, conduct process evaluation before determining the welding scheme.
- Golden Bridge TIG Welding Rods are 1 meter (39 inches) in length.
- Please note that Golden Bridge TIG welding rods are typically packaged in 5kg (11 lbs) containers. Orders less than 5 lbs will be shipped in mailing tubes to ensure safe and efficient delivery.
Thank you for choosing Foresee Electronics Inc! We understand the importance of timely delivery, especially in light of unforeseen shipping delays and increased carrier costs in 2024. Please review our shipping policy below to ensure a smooth shopping experience:
- 1. Order Processing Time: Orders are typically processed and shipped within 1-3 business days from the date of purchase. Orders placed on weekends or holidays will be processed on the next business day.
- 2. Shipping Methods and Timeframes: We ship your orders using UPS, USPS, or FedEx, selecting the best shipping handler for each order at our discretion. Delivery times typically range from 1-6 business days depending on the delivery location.
- 3. Shipping Rates: All orders purchased from this website enjoy free shipping unless otherwise stated.
- 4. Order Tracking: Once your order has been shipped, you will receive a confirmation email with tracking information. Use the provided tracking number to monitor the status of your delivery online.
- 5. At this time, we only offer shipping to the lower 48 United States, Alaska, and Hawaii. We do not ship to APO, FPO, or BO Box addresses, nor do we offer international shipping.
- 6. Contact US: If you have any questions or concerns regarding our shipping policy, please don't hesitate to contact our customer service team at info@foreseeusa.com. We're here to help!
| Diameter |
* 1/16 inches (1.6 mm), * 3/32 inches (2.5 mm), * 1/8 inches (3.2 mm) |
|---|---|
| Package |
1 lb |
