Golden Bridge
Golden Bridge E316-16 Electrode Stick Rod 11 lbs (5 kgs) 3/32",1/8",5/32" in
Golden Bridge E316-16 Electrode Stick Rod 11 lbs (5 kgs) 3/32",1/8",5/32" in
SKU:A202-2.5MM-5KG
Regular price
$119.99 USD
Regular price
Sale price
$119.99 USD
Unit price
per
In stock
Shipping calculated at checkout.
Couldn't load pickup availability
A202
A202 is a 18%Cr-12%Ni-2%Mo stainless steel welding electrode with rutile coating, which is designed for AC/DC applications. Because Mo is added to deposited metal, A202 has good corrosion resistance, heat resistance and crack resistance, especially for chloride ion pitting corrosion, and its welding performance is excellent.
The product is applicable for welding 06Cr17Ni12Mo2 stainless steel or dissimilar steel working in organic and inorganic acid (non-oxidizing acid) medium.
Chemical components of deposited metal (%)
|
Test item
|
C
|
Mn
|
Si
|
S
|
P
|
Cr
|
Ni
|
Mo
|
Cu
|
| Example value | 0.045 | 1.40 | 0.65 | 0.009 | 0.022 | 18.85 | 12.04 | 2.52 | 0.032 |
Mechanical properties of deposited metal
|
Test item
|
Rm(MPa)
|
A(%)
|
| Example value | 590 | 40 |
Reference current (AC, DC+)
|
Welding electrode diameter (mm)
|
Φ2.5
|
Φ3.2
|
Φ4.0
|
Φ5.0
|
| Welding current (A) | 50-100 | 70-130 | 100-160 | 140-200 |
1. The welding electrode should be baked at 300℃ for 1h before welding.
2. Operating with DC power supply as much as possible, and the current should not be too large.
2. Operating with DC power supply as much as possible, and the current should not be too large.
Thank you for choosing Foresee Electronics Inc! We understand the importance of timely delivery, especially in light of unforeseen shipping delays and increased carrier costs in 2024. Please review our shipping policy below to ensure a smooth shopping experience:
- 1. Order Processing Time: Orders are typically processed and shipped within 1-3 business days from the date of purchase. Orders placed on weekends or holidays will be processed on the next business day.
- 2. Shipping Methods and Timeframes: We ship your orders using UPS, USPS, or FedEx, selecting the best shipping handler for each order at our discretion. Delivery times typically range from 1-6 business days depending on the delivery location.
- 3. Shipping Rates: All orders purchased from this website enjoy free shipping unless otherwise stated.
- 4. Order Tracking: Once your order has been shipped, you will receive a confirmation email with tracking information. Use the provided tracking number to monitor the status of your delivery online.
- 5. At this time, we only offer shipping to the lower 48 United States, Alaska, and Hawaii. We do not ship to APO, FPO, or BO Box addresses, nor do we offer international shipping.
- 6. Contact US: If you have any questions or concerns regarding our shipping policy, please don't hesitate to contact our customer service team at info@foreseeusa.com. We're here to help!
| Diameter |
* 3/32 inches (2.5 mm), * 1/8 inches (3.2 mm), * 5/32 inches (4.0 mm) |
|---|---|
| Package |
11 lb (5 kg) |
